Challenger MT535D Tests
|
|
| Tractor Tests | |
| OECD 2773: diesel CVT 4WD | |
| OECD 2789: diesel AutoPower VI 4WD |
| OCED Tractor Test 2773 | |||
| |||
| OCED Tractor Test 2773 | |
| Diesel CVT 4WD March 2013 - April 2013, Link: OCED Tractor Test 2773 file | |
| PTO performance | |
| Max power | 144.4 hp 107.7 kW |
| Fuel use | 8.4 gal/hour 31.8 l/hour |
| Power at rated engine speed | 128.9 hp 96.1 kW |
| Fuel use | 7.9 gal/hour 29.9 l/hour |
| Power at rated PTO speed | 138.7 hp 103.4 kW |
| Fuel use | 8.2 gal/hour 31.0 l/hour |
| Drawbar performance | |
| Max power | 105.5 hp 78.7 kW |
| Fuel use | 7.9 gal/hour 29.9 l/hour |
| Pull at 7.8KPH | |
| Max pull | 15130 lbs 6862 kg |
| Pull at 2.96KPH | |
| OCED Tractor Test 2789 | |||
| |||
| OCED Tractor Test 2789 | |
| Diesel AutoPower VI 4WD November 2012 - July 2013, Link: OCED Tractor Test 2789 file | |
| PTO performance | |
| Max power | 141.2 hp 105.3 kW |
| Fuel use | 8.0 gal/hour 30.3 l/hour |
| Power at rated engine speed | 126.1 hp 94.0 kW |
| Fuel use | 7.5 gal/hour 28.4 l/hour |
| Power at rated PTO speed | 137.9 hp 102.8 kW |
| Fuel use | 7.9 gal/hour 29.9 l/hour |
| Drawbar performance | |
| Max power | 107.3 hp 80.0 kW |
| Fuel use | 7.2 gal/hour 27.3 l/hour |
| Gear 3A used for power test. | |
| Max pull | 13195 lbs 5985 kg |
| Gear 1F used for pull test. | |
