Challenger MT515D Tests
|
|
| OCED Tractor Test 2754 | |||
| |||
| OCED Tractor Test 2754 | |
| Diesel AutoPower IV 4WD April 2012 - May 2012, Link: OCED Tractor Test 2754 file | |
| PTO performance | |
| Max power | 135.6 hp 101.1 kW |
| Fuel use | 7.8 gal/hour 29.5 l/hour |
| Power at rated engine speed | 121.2 hp 90.4 kW |
| Fuel use | 7.3 gal/hour 27.6 l/hour |
| Power at rated PTO speed | 132.6 hp 98.9 kW |
| Fuel use | 7.6 gal/hour 28.8 l/hour |
| Drawbar performance | |
| Max power | 100.6 hp 75.0 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Gear 3A used for power test. | |
| Max pull | 11735 lbs 5322 kg |
| Gear 2A used for pull test. | |
