Massey Ferguson 7616


Massey Ferguson 7616 tractor photo
2013 - 2014
7600 Series
Row-Crop tractor
Series map:
7615
7616
7618
140.0hp
150.0hp
165.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
Built in Beauvais, France
Massey Ferguson 7616 Power
Engine (net)150 hp
111.9 kW
PTO (claimed)120 hp
89.5 kW
Drawbar (tested)107.3 hp
80.0 kW
PTO (tested)144.4 hp
107.7 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic standard
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic (optional)
 pneumatic (optional)
Cab standard. Optional hydraulic OptiRide cab suspension. AGCOCOMMAND (optional); Auto-Guide 3000 (optional)
Capacity
Fuel82 gal
310.4 L
Exhaust fluid (DEF)8 gal
30.3 L
Hydraulic system26.4 gal
99.9 L
Hydraulics
Typeclosed-center load sensing (CCLS)
 open center OptOptional
Capacity26.4 gal
99.9 L
Pressure2900 psi
200.0 bar
Valves3 (mechanical)
 4 (2 mech, 2 elec)
 4 (electric)
SCV flow24.3 gpm
92.0 lpm
Total flow29 gpm
109.8 lpm
Tractor hitch
Controlelectronic lower link draft sensing
Rear lift (at ends)9800 lbs (Dyna-6)
4445 kg
 11500 lbs (Dyna-VT)
5216 kg
Front Hitchoptional
DrawbarCat. II with drop pin
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
 540/540E/1000 (1.375)
 540/540E/1000/1000E (1.375)
Engine RPM540@1890
 540@2065 (Dyna-VT)
 540E@1533
 540E@1590 (Dyna-VT)
 1000@2030
 1000@2034 (Dyna-VT)
 1000E@1572
Dimensions & Tires
Wheelbase113.1 inches
287 cm
Weight15060 lbs
6831 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
 175 (option)
 240 (dual 120 option)
Batteries2
Battery volts12
References
7616 references literature
7600 Series published in 2013, by Massey Ferguson
