Massey Ferguson 1734E
| | 2013 - |
| 1700 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Massey Ferguson (a part of AGCO)
|
| Type: | Compact Utility tractor
|
| Massey Ferguson 1734E Power |
| Engine: | 34 hp
25.4 kW
|
| PTO (claimed): | 29 hp
21.6 kW (gear)
|
| | 27.2 hp
20.3 kW (hydro)
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | bull gear
|
| Differential lock: | rear standard
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS.
|
| Transmissions: | 9-speed gear
|
| | hydrostatic
|
 Transmission details ... |
| Hydraulics |
| Type: | open center gear pump
|
| SCV flow: | 6.7 gpm
25.4 lpm
|
| Total flow: | 10.5 gpm
39.7 lpm
|
| Steering flow: | 3.8 gpm
14.4 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 2205 lbs
1000 kg
|
| Rear lift (at 24"/610mm): | 1598 lbs
724 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live
|
| Clutch: | over-running
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2455
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
