Massey Ferguson 1759


Massey Ferguson 1759 tractor photo
2013 - 2018
1700 Series
Compact Utility tractor
1660
Series:17581759
1760M
Production
Manufacturer:Massey Ferguson
Type:Compact Utility tractor
Original price:$35,558 (2018 shuttle ROPS )
Massey Ferguson 1759 Power
Engine:59 hp
44.0 kW
PTO (claimed):45.6 hp
34.0 kW
Massey Ferguson 1759 Engine
Mitsubishi 2.2L 4-cyl diesel
Fuel tank:14.5 gal
54.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:planetary
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.
Transmission:12-speed power shuttle
Transmission details ...
Hydraulics
Type:open center gear pump
Valves:1 to 3
SCV flow:12.8 gpm
48.4 lpm
Tractor hitch
Rear Type:II
Control:position control
 draft control*Optional
Rear lift (at 24"/610mm):3307 lbs
1500 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2000
Dimensions & Tires
Wheelbase:77.2 inches
196 cm
Weight:4343 to 4784 pounds
Front tire:9.5x16
Rear tire:16.9x26
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
