Massey Ferguson 1758
| | 2013 - 2018 |
| 1700 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Massey Ferguson
|
| Type: | Compact Utility tractor
|
| Original price: | $35,068 (2018 hydrostatic ROPS )
|
| Massey Ferguson 1758 Power |
| Engine: | 59 hp
44.0 kW
|
| PTO (claimed): | 44.4 hp
33.1 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | bull gear
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS. Cab optional with air-conditioning.
|
| Transmission: | hydrostatic
|
 Transmission details ... |
| Photos |
| No photos of the Massey Ferguson 1758 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center gear pump
|
| Valves: | 1 to 3
|
| SCV flow: | 11.6 gpm
43.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| | draft control*Optional
|
| Rear lift (at 24"/610mm): | 3086 lbs
1399 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic
|
| Rear RPM: | 540 (1.375)
|
| Mid PTO: | optional
|
| Mid RPM: | 2000
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Page information |
| Last update: | May 3, 2018
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
