Tractors > Massey Ferguson > 1754

Massey Ferguson 1754

Massey Ferguson 1754 tractor photo
2013 - 2018   1700 Series
Compact Utility tractor
Previous model:Massey Ferguson 1652
Next model:Massey Ferguson 1750M
Series next:Massey Ferguson 1758
Series back:Massey Ferguson 1749






Production:

Manufacturer:Massey Ferguson
Original price (USD)
   $32,788 (2018 shuttle ROPS )


Massey Ferguson 1754 Engine:

   Mitsubishi 2.2L 4-cyl diesel
full engine details ...


Capacity:

Fuel:14.5 gal [54.9 L]


3-Point Hitch:

Rear Type:I
Control:position control
 draft control*Optional
Rear lift (at 24"/610mm):3086 lbs [1399 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2000


Dimensions & Tires:

Wheelbase:77.2 inches [196 cm]
Weight:4145 to 4575 pounds
Front tire:9.5x16
Rear tire:13.6x28
full dimensions and tires ...


Massey Ferguson 1754 attachments:

 front-end loader
all 1754 attachments ...


1754 Serial Numbers:


how to read serial numbers...



Massey Ferguson 1754 Power:

Engine:53.6 hp [40.0 kW]
PTO (claimed):42.1 hp [31.4 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Final drives:bull gear
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.


Hydraulics:

Type:open center gear pump
Valves:1 to 3
SCV flow:11.6 gpm [43.9 lpm]


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
