Massey Ferguson 1749


Massey Ferguson 1749 tractor photo
2013 - 2018
1700 Series
Compact Utility tractor
1648
Series:174217491754
1740M
Production
Manufacturer:Massey Ferguson
Type:Compact Utility tractor
Original price:$31,508 (2018 shuttle ROPS )
Massey Ferguson 1749 Power
Engine:48.3 hp
36.0 kW
PTO (claimed):39 hp
29.1 kW
Massey Ferguson 1749 Engine
Mitsubishi 1.7L 3-cyl diesel
Fuel tank:14.5 gal
54.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:bull gear
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.
Transmissions:12-speed power shuttle
 hydrostatic
Transmission details ...
Hydraulics
Type:open center gear pump
Valves:1 to 3
SCV flow:11.6 gpm
43.9 lpm
Tractor hitch
Rear Type:I
Control:position control
 draft control*Optional
Rear lift (at 24"/610mm):3086 lbs
1399 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2000
Dimensions & Tires
Wheelbase:76 inches
193 cm
Weight:3913 to 4354 pounds
Front tire:9.5x16
Rear tire:13.6x28
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
