Apollo 354
| | 2010 - |
| Compact Utility tractor | | Changfa built |
|
| Production |
| Distributor: | Apollo
|
| Manufacturer: | Changfa
|
| Type: | Compact Utility tractor
|
| Factory: | China
|
| Apollo 354 Power |
| Engine (gross): | 35 hp
26.1 kW
|
| PTO (claimed): | 32 hp
23.9 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | dual plate wet disc
|
| Cab: | Two-post foldable ROPS with canopy.
|
| Transmission: | 8-speed shuttle
|
 Transmission details ... |
| Hydraulics |
| Valves: | 2
|
| Total flow: | 8.7 gpm
32.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at 24"/610mm): | 1662 lbs
753 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540/1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 25
|
| Charging volts: | 14
|
| Battery volts: | 12
|
| Battery AH: | 80
|
