    Kubota BX2670

    Kubota BX2670 tractor photo
    2013 -    BX70 Series
    Compact Utility tractor
    Previous model:Kubota BX2660
    Smaller:Kubota BX2370






    Production:

    Manufacturer:Kubota
    Original price (USD)
       $12,896 (2013 )


    Kubota BX2670 Engine:

       Kubota 1.0L 3-cyl diesel
    full engine details ...


    Capacity:

    Fuel:6.6 gal [25.0 L]
    Hydraulic system:3.1 gal [11.7 L]


    3-Point Hitch:

    Rear Type:I
    Control:quarter-inching control
    Rear lift (at ends):1210 lbs [548 kg]
    Rear lift (at 24"/610mm):670 lbs [303 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540 (1.375)
    Engine RPMs:540@3200
    Mid PTO:independent
    Mid RPMs:2500
    Engine RPMs:2500@3200


    Dimensions & Tires:

    Wheelbase:55.1 inches [139 cm]
    Weight:1466 lbs [664 kg]
    full dimensions and tires ...


    Kubota BX2670 attachments:

     front-end loader
    all BX2670 attachments ...


    BX2670 Serial Numbers:


    - Serial numbers unknown -



    Kubota BX2670 Power:

    Engine (gross):25.5 hp [19.0 kW]
    PTO (claimed):19.5 hp [14.5 kW]


    Mechanical:

    Chassis:4x4 MFWD 4WD
    Steering:hydrostatic power
    Brakes:wet disc
    Cab:Two-post foldable ROPS. Optional canopy.


    Hydraulics:

    Type:open center
    Capacity:3.1 gal [11.7 L]
    Pump flow:6.2 gpm [23.5 lpm]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging volts:40


    Battery:

    Number:1
    Cold-cranking amps:535
    Volts:12
