Kubota BX2370
| | 2013 - 2014 |
| BX70 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Kubota
|
| Type: | Compact Utility tractor
|
| Original price: | $11,503 (2013 )
|
| Kubota BX2370 Power |
| Engine (gross): | 23 hp
17.2 kW
|
| PTO (claimed): | 17.7 hp
13.2 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | rear standard
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS. Optional canopy.
|
| Transmission: | hydrostatic
|
 Transmission details ... |
| Capacity |
| Fuel: | 6.6 gal
25.0 L
|
| Hydraulic system: | 3.1 gal
11.7 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 3.1 gal
11.7 L
|
| Pump flow: | 6.2 gpm
23.5 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | quarter-inching control
|
| Rear lift (at ends): | 992 lbs
449 kg
|
| Rear lift (at 24"/610mm): | 680 lbs
308 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@3200
|
| Mid PTO: | independent
|
| Mid RPM: | 2500
|
| Engine RPM: | 2500@3200
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 40
|
| Battery CCA: | 535
|
| Battery volts: | 12
|
