Kubota BX2370

Kubota BX2370 tractor photo
2013 - 2014   BX70 Series
Compact Utility tractor
Previous model:Kubota BX2360
Next model:Kubota BX2370-1
Series next:Kubota BX2670
Series back:Kubota BX1870






Production:

Manufacturer:Kubota
Original price (USD)
   $11,503 (2013 )


Variants:

BX2370:tractor
BX25D:loader-backhoe


Kubota BX2370 Engine:

   Kubota 0.9L 3-cyl diesel
full engine details ...


Capacity:

Fuel:6.6 gal [25.0 L]
Hydraulic system:3.1 gal [11.7 L]


3-Point Hitch:

Rear Type:I
Control:quarter-inching control
Rear lift (at ends):992 lbs [449 kg]
Rear lift (at 24"/610mm):680 lbs [308 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@3200
Mid PTO:independent
Mid RPM:2500
Engine RPM:2500@3200


Dimensions & Tires:

Wheelbase:55.1 inches [139 cm]
Weight:1410 lbs [639 kg]
Front tire:18x8.5-10
Rear tire:26x12-12
full dimensions and tires ...


Kubota BX2370 attachments:

 mowing deck
 front-end loader
all BX2370 attachments ...


BX2370 Serial Numbers:


- Serial numbers unknown -



Kubota BX2370 Power:

Engine (gross):23 hp [17.2 kW]
PTO (claimed):17.7 hp [13.2 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:rear standard
Steering:power
Brakes:wet disc
Cab:Two-post foldable ROPS. Optional canopy.


Hydraulics:

Type:open center
Capacity:3.1 gal [11.7 L]
Pump flow:6.2 gpm [23.5 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:40


Battery:

Number:1
Cold-cranking amps:535
Volts:12
