Kubota BX1870


Kubota BX1870 tractor photo
2013 - 2014
BX70 Series
Compact Utility tractor
Series map:
BX1870
BX2370
18.0hp
23.0hp
Production
ManufacturerKubota
Compact Utility tractor
Original price was $9,924 in 2013
Kubota BX1870 Engine
Kubota 0.7L 3-cyl diesel
Engine details ...
Kubota BX1870 Power
Engine (gross)18 hp
13.4 kW
PTO (claimed)13.7 hp
10.2 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Steeringhydrostatic power
Wet disc brakes
Two-post folding ROPS. Optional canopy.
Capacity
Fuel6.6 gal
25.0 L
Hydraulic system3.1 gal
11.7 L
Hydraulics
Typeopen center
Capacity3.1 gal
11.7 L
Pump flow6.3 gpm
23.8 lpm
Tractor hitch
Rear TypeI
Controlquarter-inching control
Rear lift (at ends)992 lbs
449 kg
Rear lift (at 24"/610mm)680 lbs
308 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540 (1.375)
Engine RPM540@3200
Mid PTOindependent
Mid RPM2500
Engine RPM2500@3200
Dimensions & Tires
Wheelbase52.8 inches
134 cm
Weight1345 lbs
610 kg
Front tire16x7.5-8
Rear tire24x12-12
Full dimensions and tires ...
Kubota BX1870 attachments
48" mid-mount mower deck
54" mid-mount mower deck
front-end loader
Attachment details ...
BX1870 Serial Number Location
Kubota BX1870 serial number location
Serial number on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA435
Battery volts12
