Massey Ferguson GC1705


Massey Ferguson GC1705 tractor photo
2013 - 2018
GC1700 Series
Sub-Compact Utility tractor
Iseki built
GC2400
Series:GC1705GC1715
GC1723E
Production
Distributor:Massey Ferguson
Manufacturer:Iseki
Type:Sub-Compact Utility tractor
Original price:$10,834 (2013 )
Variants
GC1705:tractor
GC1710:backhoe-loader
Massey Ferguson GC1705 Power
Engine (gross):22.5 hp
16.8 kW
PTO (claimed):18.7 hp
13.9 kW
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post folding ROPS.
Transmission:hydrostatic
Transmission details ...
Hydraulics
Type:open center
SCV flow:4.3 gpm
16.3 lpm
Total flow:6.3 gpm
23.8 lpm
Steering flow:2 gpm
7.6 lpm
Tractor hitch
Rear Type:I
Rear lift (at ends):1190 lbs
539 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Mid PTO:independent
Mid RPM:2000
Dimensions & Tires
Wheelbase:57.1 inches
145 cm
Weight:1433 lbs
650 kg
Front tire:18x8.50-10
Rear tire:26x12.00-12
Full dimensions and tires ...
Massey Ferguson GC1705 attachments
54" mid-mount mower deck
60" mid-mount mower deck
front-end loader
Attachment details ...
Electrical
Ground:negative
Battery volts:12
