Tractors > CaseIH > Farmall 105C

CaseIH Farmall 105C

CaseIH Farmall 105C tractor photo
2013 - 2015   Farmall C Series
Utility tractor
Next model:CaseIH Farmall 110C
Series next:CaseIH Farmall 115C
Series back:CaseIH Farmall 95C






Production:

Manufacturer:CaseIH


CaseIH Farmall 105C Engine:

   Fiat Powertrain Technologies (FPT) 3.4L 4-cyl diesel
full engine details ...


Capacity:

Fuel:30.3 gal [114.7 L]


Drawbar:

Drawbar:swinging drawbar


3-Point Hitch:

Rear Type:II
Control:mechanical upper-link draft sensing
Rear lift (at 24"/610mm):5620 lbs [2549 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
 540/1000*Optional


Dimensions & Tires:

4WD Wheelbase:89 inches [226 cm]
Weight:7937 lbs [3600 kg]
Rear tire:16.9R34
full dimensions and tires ...


CaseIH Farmall 105C attachments:

 front-end loader
all Farmall 105C attachments ...


Farmall 105C Serial Numbers:


- Serial numbers unknown -



CaseIH Farmall 105C Power:

Engine:106 hp [79.0 kW]
PTO (claimed):91 hp [67.9 kW]
PTO (tested):94.5 hp [70.5 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:inboard planetary
Differential lock:mechanical rear
Steering:power
ROPS Brakes:mechanical wet disc
Cab Brakes:hydraulic wet disc
Cab:Two-post foldable ROPS. Cab optional with heat and air-conditioning.


Hydraulics:

Type:open center
Valves:1 or 2
Pump flow:12.9 gpm [48.8 lpm]
 16.9 gpm [64.0 lpm] *Optional


Electrical:

Ground:negative
Charging system:alternator
Charging amps:120


Battery:

Number:1
ROPS Cold-cranking amps:730
Cab Cold-cranking amps:800
Volts:121
