Yanmar Sc2400


Yanmar Sc2400 tractor photo
2012 - 2014
Sub-Compact Utility tractor
Series map:
Sc2400
24.0hp
Production
ManufacturerYanmar
Sub-Compact Utility tractor
Variants
Sc2400compact tractor
Sc2450compact backhoe
Yanmar Sc2400 Engine
Yanmar 0.9L 3-cyl diesel
Fuel tank5.8 gal
22.0 L
Engine details ...
Yanmar Sc2400 Power
Engine (gross)24 hp
17.9 kW
Engine (net)20.4 hp
15.2 kW
PTO (claimed)16.5 hp
12.3 kW
Mechanical
Four-wheel drive
Steeringpower
Wet disc brakes
ROPS standard. Optional steel cab.
Photos
No photos of the Yanmar Sc2400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow3.5 gpm
13.2 lpm
Total flow6.9 gpm
26.1 lpm
Steering flow3.4 gpm
12.9 lpm
Tractor hitch
Rear Type1 (limited)
Controlposition control
Rear lift (at 24"/610mm)661 lbs
299 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@3111
Mid PTOindependent
Mid PTO Type2100
Engine RPM2100@3338
Dimensions & Tires
Wheelbase55.1 inches
139 cm
Weight1,280 lbs
580 kg
Front tire18x8.5-10
Rear tire26x12.0-12
Full dimensions and tires ...
Yanmar Sc2400 attachments
60" mid-mount mower deck
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery volts12
References
Sc2400 references literature
Sc2400 Sub-Compact Tractor published in 2012, by Yanmar
