J.I. Case 40-72
| | 1921 - 1923 |
| Crossmotor Series | | Standard-tread tractor |
|
| Production |
| Manufacturer: | J.I. Case
|
| Type: | Standard-tread tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Total built: | 41
|
| Original price: | $4,000
|
| J.I. Case 40-72 Power |
| Drawbar (claimed): | 40 hp
29.8 kW
|
| Belt (claimed): | 72 hp
53.7 kW
|
| Plows: | 8-10 (14-inch)
|
| Drawbar (tested): | 55.14 hp
41.1 kW
|
| Belt (tested): | 91.42 hp
68.2 kW
|
| power test details ... |
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Cab: | Open operator station.
|
| Transmission: | 2-speed gear
|
 Transmission details ... |
| Photos |
| No photos of the J.I. Case 40-72 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Belt Pulley |
| Diameter: | 19.5 inches
49 cm
|
| Width: | 10.5 inches
26 cm
|
| RPM: | 750
|
| Speed: | 3,827 ft/min
1166.47 meters/min
|
