Tractors > CaseIH > Farmall 40B

CaseIH Farmall 40B

CaseIH Farmall 40B tractor photo
2012 - 2014   Farmall B Series
Compact Utility tractor
Previous model:CaseIH Farmall 40
Next model:CaseIH Farmall 40C
Series next:CaseIH Farmall 50B
Series back:CaseIH Farmall 35B






Production:

Manufacturer:CaseIH
Original price (USD)
   $21,336 (2012 shuttle )
   $22,935 (2012 hydro )


CaseIH Farmall 40B Engine:

   Mitsubishi 2.5L 4-cyl diesel
full engine details ...


Capacity:

Fuel:9.5 gal [36.0 L]


Drawbar:

Drawbar:two-position swinging drawbar


3-Point Hitch:

Rear Type:1
Control:position control
Rear lift (at ends):2,756 lbs [1250 kg]
Rear lift (at 24"/610mm):2,469 lbs [1119 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540


Dimensions & Tires:

Wheelbase:69 inches [175 cm]
Weight:3,725 lbs [1689 kg]
full dimensions and tires ...


CaseIH Farmall 40B attachments:

 front-end loader
all Farmall 40B attachments ...


Farmall 40B Serial Numbers:


- Serial numbers unknown -



CaseIH Farmall 40B Power:

Engine (gross):41 hp [30.6 kW]
Gear PTO (claimed):34 hp [25.4 kW]
Hydro PTO (claimed):32 hp [23.9 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS.


Hydraulics:

Type:open center
Pump flow:8.2 gpm [31.0 lpm]
Gear Steering flow:4.1 gpm [15.5 lpm]
Hydro Steering flow:5.5 gpm [20.8 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:50


Battery:

Number:1
Cold-cranking amps:660
Volts:12
Amp-hours:80
