Tractors > Bolens > H1502

Bolens H1502

Bolens H1502 tractor photo
1985 - 1991
Sub-Compact Utility tractor






Production:

Distributor:Bolens
Manufacturer:Iseki


Variants:

G152:2WD gear drive
H1502:2WD hydrostatic
G154:4WD gear drive
Iseki TX2140


Bolens H1502 Engine:

   Mitsubishi 0.8L 3-cyl diesel
full engine details ...


Capacity:

Fuel:3.17 gal [12.0 L]


3-Point Hitch:

Rear Type:0/1
Control:position control


Power Take-off (PTO):

Rear RPM:454/724/1185
Engine RPM:454@2700
724@2700
1185@2700


Dimensions & Tires:

Wheelbase:50.4 inches [128 cm]
Front tire:4.50x10
Rear tire:8-16
full dimensions and tires ...


H1502 Serial Numbers:


how to read serial numbers...



Bolens H1502 Power:

Engine:15 hp [11.2 kW]


Mechanical:

Chassis:4x2 2WD
Differential lock:mechanical standard
Steering:manual
Brakes:mechanical internal expanding
Cab:Open operator station.


Hydraulics:

Type:open center
Pressure:1850 psi [127.6 bar]
Pump flow:3 gpm [11.4 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:35


Battery:

Number:1
Cold-cranking amps:305
Volts:12
