McCormick Intl X10.40M


McCormick Intl X10.40M tractor photo
2011 - 2014
X10 Series
Compact Utility tractor
Daedong built
Series:X10.35HX10.40MX10.40H
Production
Distributor:McCormick Intl
Manufacturer:Daedong
Type:Compact Utility tractor
Factory:South Korea
Variants
X10.40M:gear
X10.40H:hydrostatic
McCormick Intl X10.40M Power
Engine (gross):41 hp
30.6 kW
PTO (claimed):34 hp
25.4 kW
McCormick Intl X10.40M Engine
Daedong 2.0L 4-cyl diesel
Fuel tank:11.9 gal
45.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:rear standard
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS.
Transmission:12-speed synchronized shuttle
Transmission details ...
Hydraulics
Type:gear pump
Valves:1 or 2
Pump flow:16.8 gpm
63.6 lpm
Tractor hitch
Rear Type:I
Control:position and draft control
Rear lift (at 24"/610mm):2,493 lbs
1130 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Mid PTO:optional
Mid RPM:2000
Dimensions & Tires
Wheelbase:74 inches
187 cm
Weight:3,924 lbs
1779 kg
Front tire:8-16
Rear tire:13.6-24
Full dimensions and tires ...
Electrical
Ground:negative
Battery
Volts:12
