John Deere 2755 High Clearance


John Deere 2755 High Clearance tractor photo
1987 - 1992
55 Utility Series
High-Clearance tractor
Series:2755 High Clearance2955 High Clearance
Production
Manufacturer:John Deere
Type:High-Clearance tractor
Variants
2755:utility
John Deere 2755 High Clearance Power
John Deere 2755 High Clearance Engine
John Deere 3.9L 4-cyl diesel
Fuel tank:22.2 gal
84.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Cab:Two-post ROPS. Canopy optional.
Transmission:12-speed partially synchronized
Transmission details ...
Photos
No photos of the John Deere 2755 High Clearance are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center
Pump flow:12 gpm
45.4 lpm
Tractor hitch
Rear Type:2/1
Rear lift:3,720 lbs
1687 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:wet disc
Rear RPM:540/100
Dimensions & Tires
Wheelbase:90 inches
228 cm
Front tire:13.6-38
Rear tire:13.6-46
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging volts:55
Batteries:2
Battery CCA:400
Battery volts:12
