Tractors > John Deere > 3400

John Deere 3400



John Deere 3400 tractor photo
1995 - 1998
Utility tractor
Renault built
Series map:
3300
3400
55.9kw
63.4kw
Production
DistributorJohn Deere
ManufacturerRenault
Utility tractor
Built in Le Mans, France
John Deere 3400 Engine
John Deere 3.9L 4-cyl diesel
Fuel tank30.4 gal
115.1 L
 38.3 galOptOptional
145.0 L
Engine details ...
John Deere 3400 Transmissions
10-speed synchronized
20-speed synchronized
20-speed two-speed power shift
Transmission details ...
John Deere 3400 Power
Engine (net)85 hp
63.4 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Cab standard with heater. Optional deluxe X Cab.
Photos
No photos of the John Deere 3400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2611 psi
180.0 bar
Pump flow13.7 gpm
51.9 lpm
Steering flow7 gpm
26.5 lpm
Tractor hitch
Rear TypeII
Controllower-link draft sensing
Rear lift10071 lbs
4568 kg
Power Take-off (PTO)
Rear PTOindependent
3400 Clutchmechanical
3400X Clutchhydraulic
Rear PTO Type540/540E
 540/1000 OptOptional
Dimensions & Tires
Weight7672 lbs
3480 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps65
Battery volts12
Battery AH105
References
3400 references literature
New John Deere 3000 Series Tractors published in 1994
