John Deere 8335RT
|
|
| Production | |
| Manufacturer | John Deere |
| Agricultural Crawler tractor | |
| Built in Waterloo, Iowa, USA | |
| The John Deere 8335RT was re-tested at Nebraska (Test 1999A) to reflect the new three-point lift capacity for the 2012 model year. | |
| John Deere 8335RT Engine | |
| John Deere 9.0L 6-cyl diesel | |
 Engine details ... |
| John Deere 8335RT Transmissions | |
| 16-speed full power shift | |
| infinitely variable transmission (IVT) | |
 Transmission details ... |
| John Deere 8335RT Power | |
| Engine (gross) | 335 hp 249.8 kW |
| Engine (max) | 369 hp 275.2 kW |
| PTO (claimed) | 268 hp 199.8 kW |
| Drawbar (tested) | 250.61 hp 186.9 kW |
| PTO (tested) | 323.28 hp 241.1 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Steering | electro-hydraulic power |
| CommandView II cab standard with heat and air-conditioning. | |
| Photos | |
 | |
 John Deere 8335RT photos... | |
| Hydraulics | |
| Type | closed center pressure-flow compensated |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 3 to 5 |
| Pump flow | 35 gpm 132.5 lpm |
| Total flow | 60 gpm 227.1 lpm |
| Tractor hitch | |
| Rear Type | 4N/3 |
| Rear lift (at 24"/610mm) | 19,300 lbs (2011) 8754 kg |
| 20,000 lbs (2012-2013) 9072 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear RPM | 1000 (1-3/4) |
| Dimensions & Tracks | |
| Wheelbase | 99 inches 251 cm |
| 16-inch tracks | |
 Full dimensions and tracks ... | |
| 8335RT Serial Numbers |
| 8335RT Serial Location | |
 | |
| Serial number on the right side of main tractor frame, below the engine. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 200 |
| Batteries | 2 |
| Battery CCA | 925 |
| Battery volts | 12 |
