Massey Ferguson 2670 HD
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Utility tractor | |
| Built in Brazil | |
| Massey Ferguson 2670 HD Engine | |
| Perkins 4.4L 4-cyl diesel | |
| Fuel tank | 26.5 gal 100.3 L |
 Engine details ... | |
| Massey Ferguson 2670 HD Transmissions | |
| 8-speed synchronized shuttle | |
| 12-speed partially synchronized | |
 Transmission details ... |
| Massey Ferguson 2670 HD Power | |
| Engine (gross) | 91 hp 67.9 kW |
| PTO (claimed) | 77 hp 57.4 kW |
| PTO (tested) | 83.12 hp 62.0 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | standard |
| Power steering | |
| Hydraulic wet disc brakes | |
| ROPS. Cab optional. | |
| Hydraulics | |
| Type | open center |
| Valves | 1 to 3 |
| Pump flow | 17 gpm 64.3 lpm |
| Total flow | 25 gpm 94.6 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 3,682 lbs 1670 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| 540/1000 (optional) | |
| Dimensions & Tires | |
| Wheelbase | 90 inches 228 cm |
| Weight | 6812 to 8445 pounds |
| Front tire | 10.00-16 |
| Rear tire | 18.4-30 (2WD) |
 Full dimensions and tires ... | |
| Massey Ferguson 2670 HD attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| ROPS Charging amps | 55 |
| Cab Charging amps | 90 |
| Battery CCA | 750 |
| Battery volts | 12 |
| References | |
 | |
| New HD Series 2600 High Clearance tractors published in 2011, by Massey Ferguson | |
| HD Series 2600 published in 2012, by Massey Ferguson |
