New Holland T6080 Elite

New Holland T6080 Elite tractor photo
2007 - 2012   T6000 Series
Row-Crop tractor
Series back:New Holland T6070 Elite






Production:

Manufacturer:New Holland
Factory:Basildon, England


New Holland T6080 Elite Engine:

   FPT 6.7L 6-cyl diesel
full engine details ...


Capacity:

Fuel:79.3 gal [300.2 L]
Hydraulic system:18.5 gal [70.0 L]


3-Point Hitch:

Rear Type:2/3N
Control:electronic lower-link draft control
Rear lift:12,185 lbs [5527 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000 (1.375)


Dimensions & Tires:

Wheelbase:107.8 inches [273 cm]
 113.8 inches [289 cm] (SuperSteer)
Weight:12346 to 14585 pounds
full dimensions and tires ...


New Holland T6080 Elite attachments:

 front-end loader
all T6080 Elite attachments ...


T6080 Elite Serial Numbers:


- Serial numbers unknown -



New Holland T6080 Elite Power:

Engine (gross):155 hp [115.6 kW]
Engine (max):166 hp [123.8 kW]
PTO (claimed):135 hp [100.7 kW]
Drawbar (tested):103.5 hp [77.2 kW]
PTO (tested):149.7 hp [111.6 kW]
power test details ...


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:differential hydraulic wet disc
Cab:Horizon cab standard with air-conditioning. Optional deluxe cab with automatic temperature control and air-ride seat. Optional Comfort Ride cab suspension. Programmable headland management system.


Hydraulics:

Type:closed center load sensing
Capacity:18.5 gal [70.0 L]
Valves:2 to 4
Pump flow:26.5 gpm [100.3 lpm]
Total flow:43.6 gpm [165.0 lpm]
Steering flow:17.1 gpm [64.7 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:120
Charging volts:12


Battery:

Cold-cranking amps:1300
Volts:12
