John Deere 6910S
|
|
| Production | |
| Manufacturer | John Deere |
| Row-Crop tractor | |
| Built in Mannheim, Baden-Württemberg, Germany | |
| The John Deere 6910S featured a high power road mode for higher transport speeds. | |
| John Deere 6910S Engine | |
| John Deere 6.8L 6-cyl diesel | |
| Fuel tank | 54.7 gal 207.0 L |
| 66 gal 249.8 L | |
 Engine details ... | |
| John Deere 6910S Transmissions | |
| 24-speed | |
| 18-speed full power shift | |
 Transmission details ... |
| John Deere 6910S Power | |
| Engine | 150 hp 111.9 kW |
| PTO (claimed) | 126 hp 94.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Differential lock | electro-hydraulic wet disc |
| Power steering | |
| Hydraulic wet disc brakes | |
| TechCenter cab standard with air-conditioning. | |
| Photos | |
 | |
 John Deere 6910S photos... | |
| Hydraulics | |
| Type | closed-center load sensing |
| Pressure | 2900 psi 200.0 bar |
| Valves | 4 OptOptional |
| Pump flow | 16.6 gpm 62.8 lpm |
| 25.4 gpmOptOptional 96.1 lpm | |
| Tractor hitch | |
| Rear Type | II/IIIN |
| Control | electronic lower-link draft sensing |
| Rear Arms | telescopic link ends |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@1995 |
| 540E@1743 | |
| 1000@1995 | |
| Front PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Front PTO Type | 1000 |
| Engine RPM | 1000@1995 |
| Dimensions & Tires | |
| Wheelbase | 104.3 inches 264 cm |
| Weight | 11400 lbs 5171 kg |
| Front tire | 16.9R28 |
| Rear tire | 20.8R38 |
 Full dimensions and tires ... | |
| John Deere 6910S attachments | |
| front-end loader | |
 Attachment details ... |
| 6910S Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 90 |
| 115 OptOptional | |
| Battery volts | 12 |
| Battery AH | 154 |
| 174 OptOptional | |
| References | |
 | |
| 6010 Series Tractors: 6 cylinder 77 kW to 110 kW published in 2002, by John Deere |
