John Deere 6210L
| | 1999 - 2002 |
| 6000 TEN Series | | Orchard/Vineyard tractor |
|
| Production |
| Manufacturer: | John Deere
|
| Type: | Orchard/Vineyard tractor
|
| Factory: | Mannheim, Baden-Württemberg, Germany
|
| Variants |
| 6210: | utility tractor
|
| 6210L: | low-profile
|
| John Deere 6210L Power |
| Engine (gross): | 90 hp
67.1 kW
|
| PTO (claimed): | 72 hp
53.7 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | electro-hydraulic wet disc
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post folding ROPS.
|
| Transmissions: | 12-speed fully synchronized
|
| | 16-speed power shuttle
|
| | 16-speed partial power shift
|
| | 38-speed four-speed power shift
|
 Transmission details ... |
| Photos |
| No photos of the John Deere 6210L are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | closed center load sensing
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 1 to 4
|
| Pump flow: | 25.4 gpm
96.1 lpm
|
| | 18.9 gpm
71.5 lpm *Optional
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | electronic lower-link draft sensing
|
| Rear lift: | 4745 lbs
2152 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| | 540/1000 (1.375)*Optional
|
| 6210L Serial Numbers |
| Location: | Serial number plate on the right side of the tractor frame.
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 90
|
| Battery CCA: | 850
|
| | 1230*Optional
|
| Battery volts: | 12
|
| Battery AH: | 110
|
| | 154*Optional
|
