Tractors > Century > 3647

Century 3647



No photo available
Compact Utility tractor
Kukje built
Series map:
3642
3647
42.0hp
47.0hp
Production
DistributorCentury
ManufacturerKukje
Compact Utility tractor
Built in Yangsu-ri, South Korea
Century 3647 Engine
Kukje 2.3L 4-cyl diesel
Engine details ...
Century 3647 Transmission
12-speed partially synchronized
Transmission details ...
Century 3647 Power
Engine47 hp
35.0 kW
PTO (claimed)40 hp
29.8 kW
Mechanical
Four-wheel drive
Differential lockfoot pedal
Steeringhydrostatic power
Differential wet disc brakes
ROPS.
Photos
No photos of the Century 3647 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel11.1 gal
42.0 L
Hydraulic system9.25 gal
35.0 L
Front axle7.4 qts
7.0 L
Hydraulics
Typeopen center
Capacity9.25 gal
35.0 L
Valves1 to 3
Pump flow8.9 gpm
33.7 lpm
Total flow13.2 gpm
50.0 lpm
Tractor hitch
Rear TypeI
Rear lift2580 lbs
1170 kg
Power Take-off (PTO)
Rear PTOlive (2-stage clutch)
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase71 inches
180 cm
Weight3,910 lbs
1773 kg
Front tire8-18
Rear tire12.4-28
Full dimensions and tires ...
Century 3647 attachments
front-end loader
Attachment details ...
3647 Serial Numbers
Location:Serial number plate on the rear of the tractor, above the drawbar.
Electrical
Groundnegative
Charging amps45
Battery volts12
References
3647 references literature
Operator's Manual 2629, 2635, 3638, 3642 and 3647 (948892) published in 2003
