Landini 5-090H
| Production |
| Manufacturer | Landini
|
| Landini 5-090H Power |
| Engine | 83 hp
61.9 kW
|
| PTO (claimed) | 70.5 hp
52.6 kW
|
| Mechanical |
| Four-wheel drive |
| Wet disc brakes |
| Powerfarm cab standard. Air-conditioning and pneumatic seat optional. |
| Photos |
| No photos of the Landini 5-090H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Valves | 2 to 4
|
| Pump flow | 13.8 gpm
52.2 lpm
|
| Total flow | 21.6 gpm
81.8 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 9,570 lbs
4340 kg
|
| Front Hitch | II (optional)
|
| Front lift | 3,960 lbs
1796 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/750
|
| | 540/1000 (optional)
|
| | 540/750/1000 (optional)
|
| | ground (optional)
|
| References |
 |
| 5H Series published in 2012, by Landini |
