Cameco 405-B


Cameco 405-B tractor photo
1976 - ????
Four-wheel Drive (4WD) tractor
Production
Manufacturer:Cameco
Type:Four-wheel Drive (4WD) tractor
Factory:Thibodaux, Louisiana, USA
Cameco 405-B Power
Engine:250 hp
186.4 kW
Cameco 405-B Engine
Caterpillar 10.5L 6-cyl diesel
Engine details ...
Mechanical
Chassis:4x4 articulated 4WD
Final drives:inboard planetary
Brakes:hydraulic wet disc
Cab:Open operator station. Cab optional with air-conditioning.
Transmission:10-speed power shift
Transmission details ...
Photos
No photos of the Cameco 405-B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:150.6 gal
570.0 L
Hydraulic system:37 gal
140.0 L
Hydraulics
Type:open center
Capacity:37 gal
140.0 L
Pressure:2000 psi
137.9 bar
Valves:4
Pump flow:31.2 gpm
118.1 lpm
Tractor hitch
Rear Type:III*Optional
Dimensions & Tires
Wheelbase:135.8 inches
344 cm
Weight:22322 lbs
10125 kg
Front tire:23.1x30
Rear tire:23.1x30
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:45
Charging volts:24
Batteries:2
Battery CCA:925
Battery volts:12
