CaseIH Farmall 55A


CaseIH Farmall 55A tractor photo
2010 - 2015
Farmall A Series
Utility tractor
Series:Farmall 45AFarmall 55AFarmall 65A
Farmall 60A
Production
Manufacturer:CaseIH
Type:Utility tractor
Factory:India
CaseIH Farmall 55A Power
Engine (gross):55 hp
41.0 kW
PTO (claimed):47 hp
35.0 kW
PTO (tested):49.36 hp
36.8 kW
power test details ...
CaseIH Farmall 55A Engine
ISM 2.2L 4-cyl diesel
Fuel tank:13.5 gal
51.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:mechanical rear differential lock with foot pedal, limited slip 4WD front axle
Steering:hydrostatic power
Brakes:differential mechanical wet disc
Cab:Two-post foldable ROPS.
Transmission:8-speed synchronized shuttle
Transmission details ...
Photos
No photos of the CaseIH Farmall 55A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center fixed displacement gear pump
Valves:1 or 2
Pump flow:11.6 gpm
43.9 lpm
Total flow:16.9 gpm
64.0 lpm
Tractor hitch
Rear Type:2/1
Control:position control with mechanical draft sensing
Rear lift (at 24"/610mm):2,580 lbs
1170 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
4WD Wheelbase:87 inches
220 cm
Weight:3770 to 4385 pounds
Front tire:6x16
2WD Rear tire:14.9x28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:55
Battery CCA:800
Battery volts:12
