McCormick Intl CT55U
| 2008 - 2010 |
CTU Series | Compact Utility tractor |
|
Production |
Manufacturer: | McCormick Intl (a part of Argo)
|
Type: | Compact Utility tractor
|
McCormick Intl CT55U Power |
Engine: | 47 hp 35.0 kW
|
PTO (claimed): | 44 hp 32.8 kW
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Steering: | hydrostatic power
|
Brakes: | wet disc
|
Cab: | ROPS. Cab optional.
|
Transmission: | 16-speed
|
Transmission details ... |
Photos |
No photos of the McCormick Intl CT55U are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Valves: | 2
|
Pump flow: | 9.1 gpm 34.4 lpm
|
Steering flow: | 4.7 gpm 17.8 lpm
|
Tractor hitch |
Rear Type: | I
|
Rear lift (at ends): | 3,300 lbs 1496 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 540
|
Electrical |
Ground: | negative
|
Battery volts: | 12
|
