McCormick Intl F75


McCormick Intl F75 tractor photo
2004 - 2008
F Series
Orchard/Vineyard tractor
Series:F70F75F80
Production
Manufacturer:McCormick Intl (a part of Argo)
Type:Orchard/Vineyard tractor
Variants
F75:standard narrow
F75XL:wide deluxe
McCormick Intl F75 Power
Engine:68 hp
50.7 kW
PTO (claimed):63 hp
47.0 kW
McCormick Intl F75 Engine
Perkins 4.4L 4-cyl diesel
F/GE Fuel tank:12.7 gal
48.1 L
F/GE Fuel tank:19.3 gal
73.1 L *With optional 25L tank
XL Fuel tank:17.2 gal
65.1 L
XL Fuel tank:23.8 gal
90.1 L *With optional 25L tank
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post mid-mount folding ROPS. Cab optional.
Transmissions:15-speed mechanical shuttle
 15-speed power shuttle
 30-speed two-speed power shift
Transmission details ...
Photos
No photos of the McCormick Intl F75 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
F/GE Valves:2
XL Valves:3
Pump flow:13.8 gpm
52.2 lpm
Total flow:21.7 gpm
82.1 lpm
Steering flow:7.9 gpm
29.9 lpm
Tractor hitch
Rear Type:II
Rear lift:5732 lbs
2600 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:dry disc
 wet disc*With power shuttle transmissions
Rear RPM:540/750
 540/1000
Dimensions & Tires
2WD Wheelbase:85.6 inches
217 cm
4WD Wheelbase:84 inches
213 cm
Weight:5766 to 6714 pounds
Front tire:7.50-16
Rear tire:14.9R24
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:85
