New Holland T4050

New Holland T4050 tractor photo
2008 - 2011   T4000 Series
Utility tractor
Next model:New Holland T4.115
Series back:New Holland T4040






Production:

Manufacturer:New Holland
Factory:Jesi, Italy


Variants:

T4050:standard chassis
T4050F:narrow chassis
T4050V:ultra-narrow chassis
TK4050:crawler
TK4050M:mountain (wide) crawler


New Holland T4050 Engine:

   New Holland 4.5L 4-cyl diesel
full engine details ...


Capacity:

Fuel:21.6 gal [81.8 L]
 23.2 gal [87.8 L] (Deluxe)


3-Point Hitch:

Rear Type:II/I
Rear lift (at 24"/610mm):3,962 lbs [1797 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540
 540/1000 (optional)


Dimensions & Tires:

Wheelbase:83.7 inches [212 cm] (4WD)
 86.0 inches [218 cm] (4WD deluxe)
 86.7 inches [220 cm] (2WD)
 89.0 inches [226 cm] (2WD deluxe)
 98.2 inches [249 cm] (SuperSteer)
Weight:6614 to 7055 pounds
full dimensions and tires ...


New Holland T4050 attachments:

 front-end loader
all T4050 attachments ...


T4050 Serial Numbers:


- Serial numbers unknown -



New Holland T4050 Power:

Engine (gross):95 hp [70.8 kW]
PTO (claimed):80 hp [59.7 kW]
Drawbar (tested):74.3 hp [55.4 kW]
PTO (tested):89.7 hp [66.9 kW]
power test details ...


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:hydraulic wet disc
Cab:Platform with ROPS. Cab on deluxe model with heat and air-conditioning.


Hydraulics:

Type:open center
Pressure:2,755 psi [190.0 bar]
Valves:1 to 5
Pump flow:16.1 gpm [60.9 lpm]
Steering flow:9.4 gpm [35.6 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:120


Battery:

Number:1
Cold-cranking amps:800
Volts:12
