Kubota M128X
|
|
| Production | |
| Manufacturer | Kubota |
| Row-Crop tractor | |
| Kubota M128X Engine | |
| Kubota 6.1L 4-cyl diesel | |
| Fuel tank | 50.2 gal 190.0 L |
 Engine details ... | |
| Kubota M128X Transmissions | |
| 16-speed partial powershift | |
| 24-speed | |
 Transmission details ... |
| Kubota M128X Power | |
| Engine (gross) | 134 hp 99.9 kW |
| Engine | 128 hp 95.4 kW |
| PTO (claimed) | 113 hp 84.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Photos | |
| No photos of the Kubota M128X are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 2 to 4 |
| Pump flow | 20.4 gpm 77.2 lpm |
| Steering flow | 15.3 gpm 57.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 5,203 lbs 2360 kg |
| 9,447 lbs (optional) 4285 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 105.9 inches 268 cm |
| Weight | 9,722 lbs 4409 kg |
| Front tire | 420/70R24 |
| Rear tire | 520/70R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 80 |
| References | |
 | |
| M128X published in 2008, by Kubota |
