Kubota M128X
| | 2008 - 2010 |
| Row-Crop tractor |
|
| Production |
| Manufacturer: | Kubota
|
| Type: | Row-Crop tractor
|
| Kubota M128X Power |
| Engine (gross): | 134 hp
99.9 kW
|
| Engine: | 128 hp
95.4 kW
|
| PTO (claimed): | 113 hp
84.3 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Transmissions: | 16-speed partial powershift
|
| | 24-speed
|
 Transmission details ... |
| Photos |
| No photos of the Kubota M128X are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Valves: | 2 to 4
|
| Pump flow: | 20.4 gpm
77.2 lpm
|
| Steering flow: | 15.3 gpm
57.9 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at 24"/610mm): | 5,203 lbs
2360 kg
|
| | 9,447 lbs
4285 kg (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 80
|
| Page information |
| Last update: | November 8, 2018
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
