Iseki TK532


No photo available
2001 - ????
TK Series
Compact Utility tractor
Series:TK527TK532TK538
Production
Manufacturer:Iseki
Type:Compact Utility tractor
Iseki TK532 Power
Engine (gross):34 hp
25.4 kW
Engine (net):31.6 hp
23.6 kW
Iseki TK532 Engine
Iseki 1.5L 3-cyl diesel
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power assist
Brakes:mechanical wet disc
Cab:Open operator station. Cab available.
Transmission:16-speed mechanical shuttle
Transmission details ...
Photos
No photos of the Iseki TK532 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:7.9 gal
29.9 L
Steering:0.3 qts
0.3 L
Hydraulics
Type:open center
Pressure:1916 psi
132.1 bar
Total flow:9.7 gpm
36.7 lpm
Steering flow:6 gpm
22.7 lpm
Steering cap.:0.3 qts
0.3 L
Tractor hitch
Rear Type:I
Control:position control with available draft control
Rear lift (at ends):2866 lbs
1300 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:67.9 inches
172 cm
Weight:2557 lbs
1159 kg
Front tire:7x16
Rear tire:12.4x24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:40
Battery volts:12
Battery AH:65
