Iseki TU217


Iseki TU217 tractor photo
1989 - 1992
TU 7 Series
Compact Utility tractor
Series:TU197TU217TU237
Production
Manufacturer:Iseki
Type:Compact Utility tractor
Variants
TU217F:4WD
Iseki TU217 Power
Engine:20.7 hp
15.4 kW
Iseki TU217 Engine
Isuzu 1.4L 3-cyl diesel
Fuel tank:6.6 gal
25.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Cab:Open operator station
Transmission:12-speed
Transmission details ...
Photos
No photos of the Iseki TU217 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:JIS0
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:553@2500
847@2500
1309@2500
Dimensions & Tires
Wheelbase:57.5 inches
146 cm
Weight:1885 to 2094 pounds
Front tire:4.00-15
2WD Rear tire:9.5-22
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
