Iseki TL3201


Iseki TL3201 tractor photo
1980 - 1985
TL-01 Series
Compact Utility tractor
Series:TL2901TL3201TL4201
Production
Manufacturer:Iseki
Type:Compact Utility tractor
Variants
TL3201:2WD
TL3201F:4WD
TL3205:4WD high-speed
Iseki TL3201 Power
Engine:31.6 hp
23.6 kW
Iseki TL3201 Engine
Isuzu 1.5L 4-cyl diesel
Fuel tank:10.6 gal
40.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Cab:Open operator station.
Transmission:18-speed
Transmission details ...
Photos
No photos of the Iseki TL3201 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:JIS1
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:593@2600
722@2600
945@2600
1541@2600
Dimensions & Tires
Wheelbase:71.1 inches
180 cm
Weight:2932 to 3208 pounds
Front tire:6.00-16
2WD Rear tire:13.6-26
Full dimensions and tires ...
