Iseki TH4290


Iseki TH4290 tractor photo
2004 - 2008
TH Series
Compact Utility tractor
Series:TH4260TH4290TH4330
Production
Manufacturer:Iseki
Type:Compact Utility tractor
Iseki TH4290 Power
Engine:27.6 hp
20.6 kW
Iseki TH4290 Engine
Iseki 1.5L 3-cyl diesel
Fuel tank:7.9 gal
29.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS.
Transmission:9-speed gear
Transmission details ...
Photos
No photos of the Iseki TH4290 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Total flow:7.4 gpm
28.0 lpm
Tractor hitch
Rear Type:1
Rear lift (at ends):2,425 lbs
1099 kg
Power Take-off (PTO)
Hydro Rear PTO:independent
Clutch:electro-hydraulic
Gear Rear RPM:540
Hydro Rear RPM:540/1000
Engine RPM:540@2324
1000@2381
Front RPM:2000
Dimensions & Tires
Wheelbase:65.6 inches
166 cm
Weight:2127 to 2172 pounds
Front tire:7-14
Rear tire:9.5-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:40
Battery volts:12
