White Workhorse 125


White Workhorse 125 tractor photo
1990 - 1992
Workhorse Series
Row-Crop tractor
Series map:
125
145
132.4hp*
153.9hp*
*Estimated engine power for comparison only.
Production
ManufacturerWhite
Row-Crop tractor
Original price was $55,000 in 1992
White 125 Engine
CDC-Cummins 5.9L 6-cyl diesel
Fuel tank58 gal
219.5 L
Engine details ...
White 125 Power
Drawbar (tested)103.03 hp
76.8 kW
PTO (tested)119.13 hp
88.8 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Differential lockhydraulic rear
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Hydraulics
Typeopen center
Pressure2250 psi
155.1 bar
Rear valves2 or 3
Pump flow22 gpm
83.3 lpm
Tractor hitch
Rear TypeIII/II
Controllower-link draft sensing
Rear lift7223 lbs
3276 kg
 8444 lbsOptOptional
3830 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/1000
Dimensions & Tires
2WD Wheelbase111.5 inches
283 cm
4WD Wheelbase99 inches
251 cm
Weight14465 lbs
6561 kg
Front tire10.00-16
Rear tire18.4R-38
Full dimensions and tires ...
125 Serial Numbers
Location:Left rear side of frame
1990404066
1991404601
1992500001

FAQ: How to read a serial number table.
Electrical
Groundnegative
References
Workhorse 125 references literature
Workhorse Tractors published in 1990, by White
Workhorse Tractors published in 1990, by White
