Farmtrac 60
| | 1998 - 2003 |
| Utility tractor |
|
| Production |
| Manufacturer: | Farmtrac
|
| Type: | Utility tractor
|
| Farmtrac 60 Power |
| Engine: | 49.7 hp
37.1 kW
|
| PTO (claimed): | 44.7 hp
33.3 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| | hydrostatic power (optional)
|
| Brakes: | mechanical dry disc
|
| Cab: | Two-post ROPS.
|
| Transmission: | 8-speed constant mesh
|
 Transmission details ... |
| Capacity |
| Fuel: | 13 gal
49.2 L
|
| Hydraulic system: | 6.3 gal
23.8 L
|
| Hydraulics |
| Type: | gear pump
|
| Capacity: | 6.3 gal
23.8 L
|
| Valves: | 2
|
| Pump flow: | 4.5 gpm
17.0 lpm
|
| | 9 gpm
34.1 lpm *Optional
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift (at ends): | 3,087 lbs
1400 kg
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| | live (two-stage clutch)
|
| Clutch: | 11-inch dry disc
|
| Rear RPM: | 540 (1.375)
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 55
|
| Battery CCA: | 800
|
| Battery volts: | 12
|
