    Farmtrac 60

    Farmtrac 60 tractor photo
    1998 - 2003
    Utility tractor






    Production:

    Manufacturer:Farmtrac


    Farmtrac 60 Engine:

       Escorts 3.1L 3-cyl diesel
    full engine details ...


    Capacity:

    Fuel:13 gal [49.2 L]
    Hydraulic system:6.3 gal [23.8 L]


    3-Point Hitch:

    Rear Type:II
    Control:position and draft control
    Rear lift (at ends):3,087 lbs [1400 kg]


    Power Take-off (PTO):

    Rear PTO:transmission
     live (two-stage clutch)
    Clutch:11-inch dry disc
    Rear RPMs:540 (1.375)


    Dimensions & Tires:

    Wheelbase:82.3 inches [209 cm]
    Weight:4,519 lbs [2049 kg]
    Front tire:6.00x16
    Rear tire:14.9x28
    full dimensions and tires ...


    60 Serial Numbers:


    - Serial numbers unknown -



    Farmtrac 60 Power:

    Engine:49.7 hp [37.1 kW]
    PTO (claimed):44.7 hp [33.3 kW]


    Mechanical:

    Chassis:4x2 2WD
    Steering:manual
     hydrostatic power (optional)
    Brakes:mechanical dry disc
    Cab:Two-post ROPS.


    Hydraulics:

    Type:gear pump
    Capacity:6.3 gal [23.8 L]
    Valves:2
    Pump flow:4.5 gpm [17.0 lpm]
     9 gpm [34.1 lpm] (optional)


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:55


    Battery:

    Number:1
    Cold-cranking amps:800
    Volts:12
