J.I. Case 4994
|
|
| Production | |
| Manufacturer | J.I. Case |
| Four-wheel Drive (4WD) tractor | |
| Built in Racine, Wisconsin, USA | |
| Total built | 224 |
| Original price was $132,050 in 1985 | |
| J.I. Case 4994 Engine | |
| Saab-Scania 14.2L 8-cyl diesel | |
 Engine details ... |
| J.I. Case 4994 Transmission | |
| 12-speed full power shift | |
 Transmission details ... |
| J.I. Case 4994 Power | |
| Engine | 400 hp 298.3 kW |
| PTO (claimed) | 344 hp 256.5 kW |
| Drawbar (tested) | 294.24 hp 219.4 kW |
| PTO (tested) | 344 hp 256.5 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | 4x4 4WD |
| Steering | hydraulic, front, rear or four-wheel crab steering |
| Hydraulic dual caliper disc brakes | |
| Silent Guardian cab standard | |
| Photos | |
 | |
 J.I. Case 4994 photos... | |
| Capacity | |
| Fuel | 300 gal 1135.5 L |
| Hydraulic system | 26.25 gal 99.4 L |
| Front hubs | 13.5 qts (each) 12.8 L |
| Front diff. | 17 qts 16.1 L |
| Rear hubs | 13.5 qts (each) 12.8 L |
| Rear diff. | 22.5 qts 21.3 L |
| Hydraulics | |
| Type | closed center |
| Capacity | 26.25 gal 99.4 L |
| Pressure | 2000 psi 137.9 bar |
| Valves | 2 to 4 |
| Pump flow | 35 gpm 132.5 lpm |
| Total flow | 35 gpm 132.5 lpm |
| Steering flow | 20 gpm 75.7 lpm |
| Steering press. | 2000 psi 137.9 bar |
| Tractor hitch | |
| Rear Type | IV/IVN (optional) |
| Rear lift (at 24"/610mm) | 16,000 lbs 7257 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Rear PTO Type | 1000 (1.75) |
| Engine RPM | 1000@2100 |
| Dimensions & Tires | |
| Wheelbase | 124.8 inches 316 cm |
| Weight | 26500 to 31315 pounds |
| Front tire | 24.5-32 |
| Rear tire | 24.5-32 |
 Full dimensions and tires ... | |
| 4994 Serial Numbers | |
| Location: | Data plates located at forward-right corner in top of the tractor cab. |
| 1984 | 8865000 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 105 |
| Batteries | 2 |
| Battery volts | 12 |
| Battery AH | 300 |
| Battery Group | 30H |
| References | |
 | |
| 4994 Tractor Operators Manual (9-9870) published in 1984 | |
| Tractor & Loaders Buyers Guide published in 1985, by J.I. Case |
