Ford 8530
| | 1990 - 1993 |
| 8030 Series | | Row-Crop tractor |
|
Series map:
8530
8630
116.7hp*
134.4hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | Ford
|
| Row-Crop tractor |
| Built in Antwerp, Belgium |
| Original price was $46,000 in 1993 |
| Ford 8530 Power |
| Drawbar (claimed) | 92 hp
68.6 kW
|
| PTO (claimed) | 105 hp
78.3 kW
|
| Drawbar (tested) | 92.62 hp
69.1 kW
|
| PTO (tested) | 105.74 hp
78.9 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Power disc brakes |
| optional cab with heat and A/C |
| Photos |
| No photos of the Ford 8530 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 33 gal
124.9 L
|
| | 24.5 gal (auxiliary tank)
92.7 L
|
| Steering | 2 qts
1.9 L
|
| Hydraulics |
| Type | open center gear pump, dual pumps optional
|
| Pressure | 2500 psi
172.4 bar
|
| Pump flow | 20.9 gpm
79.1 lpm
|
| | 29.6 gpm (dual pumps)
112.0 lpm
|
| SCV flow | 17.6 gpm
66.6 lpm
|
| | 19.0 gpm (dual pumps)
71.9 lpm
|
| Steering cap. | 2 qts
1.9 L
|
| Steering press. | 2025 psi
139.6 bar
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear RPM | 540/1000
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 90
|
| Battery volts | 12
|
| References |
 |
| Front-end Loaders published in 1992, by Ford |
| Front-end Loaders published in 1995, by New Holland |
| 8030 Series Tractors published in 1990, by Ford |
| Operator's Manual 8530 - 8630 - 8730 - 8830 (SE4812) published in 1990 |
