John Deere 5105M - engine

John Deere 5105M tractor photo
2008 - 2011   5M Series
Utility tractor
Previous model:John Deere 5625
Next model:John Deere 5115M
Series back:John Deere 5095M
more John Deere 5105M specifications...






Engine Detail:

 John Deere PowerTech E 4045
 turbocharged diesel
 4-cylinder
 liquid-cooled
 276 ci [4.5 L]
Bore/Stroke:4.19x5.00 inches [106 x 127 mm]
Emissions:Tier 3
Power:105 hp [78.3 kW]
Air cleaner:dry
Rated RPM:2200
Torque:420 lb-ft [569.5 Nm]
Torque RPM:1400
Starter volts:12
Oil capacity:8.8 qts [8.3 L]
Coolant capacity:12 qts [11.4 L]
