    John Deere 5093E

    John Deere 5093E tractor photo
    2008 - 2015   5E Limited Series
    Model years
    Utility tractor
    Larger:John Deere 5101E
    Smaller:John Deere 5083E






    Production:

    Manufacturer:John Deere
    Factory:Augusta, Georgia, USA
    Original price (USD):$44,848 (2011)


    Variants:

    5093E:utility chassis
    5093EN:narrow chassis


    John Deere 5093E Engine:

       John Deere 4.5L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:33.5 gal [126.8 L]


    3-Point Hitch:

    Rear Type:2/1
    Control:position control and top-link draft sensing
    Rear lift (at 24"/610mm):3,213 lbs [1457 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:mechanical
    Rear RPM:540/540E
     540/1000 (optional)


    Dimensions & Tires:

    Wheelbase:85.8 inches [217 cm]
    Weight:7,385 lbs [3349 kg]
    Front tire:11.2-24
    Rear tire:16.9-30
    full dimensions and tires ...


    John Deere 5093E attachments:

     front-end loader
    all 5093E attachments ...


    5093E Serial Numbers:

    Location:Left side of tractor above front axle.

    - Serial numbers unknown -



    John Deere 5093E Power:

    Engine (gross):93 hp [69.4 kW]
    PTO (claimed):75 hp [55.9 kW]
    PTO (tested):80.94 hp [60.4 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 MFWD 4WD
    Final drives:planetary
    Differential lock:rear standard
    Steering:hydrostatic power
    Brakes:independent hydraulic wet disc
    Cab:Cab standard with heat and air-conditioning.


    Hydraulics:

    Type:open center
    Pressure:2828 psi [195.0 bar]
    Rear valves:1 to 3
    Mid valves:2 (optional)
    Pump flow:15.9 gpm [60.2 lpm]
    Total flow:22.5 gpm [85.2 lpm]
    Steering flow:6.6 gpm [25.0 lpm]
    Steering press.:1900 psi [131.0 bar]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:90
     120 (optional)


    Battery:

    Number:1
    Cold-cranking amps:950
    Volts:12
