CaseIH Farmall DX60
|
|
| Production | |
| Distributor | CaseIH |
| Manufacturer | Shibaura |
| Compact Utility tractor | |
| CaseIH DX60 Engine | |
| Shibaura 2.2L 4-cyl diesel | |
| Fuel tank | 13.5 gal 51.1 L |
 Engine details ... | |
| CaseIH DX60 Transmissions | |
| 12-speed sync shuttle | |
| 12-speed power shuttle | |
 Transmission details ... |
| CaseIH DX60 Power | |
| Engine (gross) | 60 hp 44.7 kW |
| PTO (claimed) | 50 hp (power shuttle) 37.3 kW |
| 51 hp (synchro) 38.0 kW | |
| PTO (tested) | 51.57 hp 38.5 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Differential wet disc brakes | |
| Two-post ROPS. | |
| Photos | |
| No photos of the CaseIH DX60 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Total flow | 17.53 gpm 66.4 lpm |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 74.8 inches 189 cm |
| Weight | 4209 to 4238 pounds |
 Full dimensions and tires ... | |
| References | |
 | |
| DX Series Farmall Tractors published in 2007, by CaseIH |
