Fendt 209
| | 2003 - 2009 |
| Farmer 200 Series | | Utility tractor |
|
| Production |
| Manufacturer: | Fendt (a part of AGCO)
|
| Type: | Utility tractor
|
| Fendt 209 Power |
| Engine (gross): | 92.5 hp
69.0 kW
|
| Engine (net): | 88.5 hp
66.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic disc
|
| Cab: | Cab standard with available heat and air-conditioning.
|
| Transmissions: | 21-speed synchromesh
|
| | 21-speed shuttle
|
 Transmission details ... |
| Photos |
| No photos of the Fendt 209 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 2 or 3
|
| Pump flow: | 12.4 gpm
46.9 lpm
|
| | 19.6 gpm
74.2 lpm *Optional
|
| Tractor hitch |
| Rear Type: | 2
|
| Front Hitch: | optional
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/750/1000
|
| | 540/750/ground*Optional
|
| Front PTO: | independent*Optional
|
| Front RPM: | 540
|
| | 1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 95
|
| Charging volts: | 14
|
| Battery volts: | 12
|
| Battery AH: | 88
|
