Tractors > CaseIH > Steiger 385QT Quadtrac

CaseIH Steiger 385QT Quadtrac - engine

CaseIH Steiger 385QT Quadtrac tractor photo
2008 - 2010
Series next:CaseIH Steiger 435QT
more CaseIH Steiger 385QT Quadtrac specifications...






Engine Detail:

 Iveco
 turbocharged aftercooled diesel
 6-cylinder 24-valve
 liquid-cooled
 786 ci [12.9 L]
Bore/Stroke:5.314x5.906 inches [135 x 150 mm]
Emissions:Tier 3
Power:385 hp [287.1 kW]
Maximum Power:423 hp [315.4 kW]
Air cleaner:dual paper elements
Compression:16.5:1
Rated RPM:2000
Starter volts:24
Oil capacity:32.8 qts [31.0 L]
