AGCO RT100A


AGCO RT100A tractor photo
2006 - 2007
RT-A Series
Row-Crop tractor
Series map:
RT100A
128.0hp
Production
ManufacturerAGCO
Row-Crop tractor
Built in Beauvais, France
AGCO RT100A Engine
Sisu 6.6L 6-cyl diesel
Fuel tank70 gal
264.9 L
Engine details ...
AGCO RT100A Transmissions
continuously variable transmission
32-speed partial power shift
Transmission details ...
AGCO RT100A Power
Engine128 hp
95.4 kW
PTO (claimed)100 hp
74.6 kW
Drawbar (tested)89.72 hp
66.9 kW
PTO (tested)117.73 hp
87.8 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Steeringhydrostatic power
Hydraulic wet disc brakes
Cab standard.
Hydraulics
Typeclosed center PFC
Valves3 or 4
Pump flow29 gpm
109.8 lpm
Tractor hitch
Rear TypeII, IIIN
Rear lift8,500 lbs
3855 kg
 10,500 lbs
4762 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase109.5 inches
278 cm
Weight15,100 lbs
6849 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Batteries2
Battery volts12
