Kubota BX1800
| | 2001 - 2003 |
| BX Series | | Sub-Compact Utility tractor |
|
Series map:
BX1800
BX2200
18.0hp
22.0hp
| Production |
| Manufacturer | Kubota
|
| Sub-Compact Utility tractor |
| Kubota BX1800 Power |
| Engine (gross) | 18 hp
13.4 kW
|
| PTO (claimed) | 13.7 hp
10.2 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post ROPS. |
| Tractor hitch |
| Rear Type | 1
|
| Rear lift | 652 lbs
295 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | independent
|
| Mid PTO Type | 2500
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Diesel Tractor BX1800/BX2200 published in 2000, by Kubota |
