Yanmar FX255


Yanmar FX255 tractor photo
1987 - 1992
Compact Utility tractor
Series:FX235FX255FX265
Production
Manufacturer:Yanmar
Type:Compact Utility tractor
Variants
F255:2WD gear
F255D:4WD gear
FX255:2WD power shift
FX255D:4WD power shift
Yanmar FX255 Power
Engine:24.7 hp
18.4 kW
Yanmar FX255 Engine
Yanmar 1.5L 3-cyl diesel
Fuel tank:6.6 gal
25.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Cab:Open operator station.
Transmissions:9-speed partial power shift
 18-speed creeper
Transmission details ...
Tractor hitch
Rear Type:JIS1
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:574@2500
698@2500
956@2500
1293@2500
Dimensions & Tires
2WD Wheelbase:59.5 inches
151 cm
4WD Wheelbase:60 inches
152 cm
Weight:2205 to 2370 pounds
Front tire:5.00-15
2WD Rear tire:11.2-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:16
Battery volts:12
Battery AH:75
